ACCU SLIT

Home Our Businesses Engineering Products Converting Machines Slitting / Rewinding Machines Accu Slit

Machine Picture

UFlex Engg Business

Technical Data

GENERAL SPECIFICATION
  • Machine Type: Accu Slit 30
  • Working Width: Max. 3050 mm (without oscillation)
  • Material Width: Max. 3050 mm & Min 800 mm
  • Machine Speed: Max. 800 m/min
UNWIND
  • Type: Floor Pickup
    Parent roll:
  • Diameter: Max. 1200 mm
  • Weight including Core: Max. 3000 kg on 6" & Max. 4000 kg on 3"
WEB GUIDER
  • Type: Automatic Web Controller
  • Scanner: Ultrasonic Edge Sensor FX 4060
  • Type of Scanning: Edge
REWIND
  • Winding Concept: Individual Winding Stations with Centre Drive
  • Type of Rewind: Contact Winding
  • Finished Roll Diameter: Min.400 mm & Max. 1200 mm

Click Here to Download Converting Slitting / Rewinding Machines (ACCU SLIT) Product Catalogue.
